Cable Braiding & Shielding
Wire braiding and shielding services providing electromagnetic interference protection and mechanical durability for demanding cable applications.
Braiding Processes
Our cable braiding and shielding capabilities for EMI protection.
Copper Braiding
Standard and tinned copper braid shielding
EMI/RFI Protection
Effective electromagnetic interference shielding
High Coverage
Up to 95%+ braid coverage available
Mechanical Protection
Abrasion and cut resistance
Custom Diameters
Braiding for various cable sizes
High Speed
Automated braiding for volume production
Shielding Excellence
Electromagnetic interference can disrupt sensitive signals and electronics. Our braiding and shielding services protect your cables from EMI/RFI while adding mechanical durability.
- Bare copper braid
- Tinned copper braid
- Stainless steel braid
- Nickel-plated braid
- Expandable sleeving
- 85% to 95%+ coverage
- Custom braid patterns
- Ground strap termination
Technical Specifications
Our cable braiding equipment and material specifications.
Signal Protection
Whether protecting sensitive signals from external interference or containing emissions from high-speed circuits, our braiding solutions deliver the shielding performance your application requires.
EMI Shielding
Electromagnetic protection
RFI Blocking
Radio frequency isolation
Abrasion
Mechanical protection
Flexibility
Maintains cable flex
Cable Braiding and Shielding Services for EMI Protection
As a specialized cable braiding and EMI shielding provider, OurPCB delivers copper braid shielding with 85% to 95%+ coverage for electromagnetic interference protection. Our automated braiding equipment processes cables from 1mm to 50mm+ diameter for shielded cable and wire harness applications requiring RF protection.
Braid material options include bare copper for maximum conductivity, tinned copper for corrosion resistance, stainless steel for strength and temperature, and nickel-plated copper for specific environments. Proper braid selection depends on shielding frequency range, environmental conditions, and mechanical requirements.
Our braiding serves coaxial cables and RF assemblies, medical device signal cables requiring EMI protection, and aerospace avionics wiring. Telecommunications and data applications benefit from proper shielding for signal integrity.
Shield termination options include solder sleeve, crimp ferrule, heat shrink, and pigtail drain wire. Proper termination ensures shield effectiveness at connectors. Expandable braided sleeving provides mechanical abrasion protection in addition to or instead of EMI shielding.
Over-braiding adds shielding to existing cables or cable assemblies for retrofit applications. Our testing capabilities verify shield effectiveness. Contact us for cable braiding quotes for your EMI shielding and mechanical protection requirements.
Braiding FAQ
Braid shielding effectiveness depends on coverage percentage and material. Standard 85% coverage provides good general shielding. 95%+ coverage with proper termination provides excellent high-frequency shielding for demanding applications.
We offer bare copper, tinned copper (for corrosion resistance), stainless steel (for strength and temperature), and nickel-plated copper (for specific environments). Material selection depends on shielding needs and operating conditions.
Yes, we can add over-braiding to existing cables or cable assemblies. This is common for adding shielding to unshielded cables or adding mechanical protection over jacketed cables.
Braid termination options include solder sleeve, crimp ferrule, heat shrink, and pigtail drain wire. Proper termination ensures shield effectiveness and reliable grounding at connectors.
Need Cable Braiding Services?
EMI/RFI shielding and mechanical protection with copper, tinned copper, and stainless steel braiding for your cable assemblies.
