Solar Wire Harness
Wire harness and cable assemblies for solar and photovoltaic systems. UV-resistant, outdoor-rated cables for residential and commercial installations.
Solar Applications
Wire harness solutions for solar and energy storage systems.
Panel Connections
Module interconnects, string wiring, junction boxes
Inverter Systems
DC input cables, AC output, monitoring connections
Energy Storage
Battery connections, BMS wiring, hybrid systems
Monitoring
Data cables, sensors, communication systems
Residential
Rooftop systems, microinverters, rapid shutdown
Commercial
Large-scale arrays, utility connections, ground mount
Built for the Elements
Solar installations face decades of sun exposure, temperature cycling, and weather extremes. Our cables are designed for long-term outdoor performance with materials rated for 25+ years.
- MC4 compatible connectors
- UV-resistant materials
- Outdoor rated (UL 4703)
- High-voltage DC cables
- Pre-terminated strings
- Custom lengths
- Rapid shutdown compliant
- Weather-sealed construction
Solar Capabilities
Our capabilities for solar wire harness manufacturing.
Complete PV Wiring Solutions
From string cables to inverter connections, we provide complete wiring solutions for residential, commercial, and utility-scale solar installations.
String Cables
Pre-terminated module connections
DC Home Runs
Array to inverter cabling
AC Output
Inverter to grid connections
Monitoring
Data and communication cables
Solar Wire Harness Manufacturing for Photovoltaic Systems
As a specialized solar wire harness manufacturer, OurPCB delivers UV-resistant, outdoor-rated cables for photovoltaic systems. Our cable assembly expertise covers MC4-compatible connectors, DC power cables up to 1500V, and pre-terminated string cables meeting UL 4703 and TUV standards for 25+ year outdoor life.
Panel connections include module interconnects, string wiring, and junction box cables for residential and commercial arrays. Inverter cables handle DC input, AC output, and monitoring connections. Waterproof cables protect electrical connections from rain and humidity.
Energy storage cables connect battery systems in hybrid solar installations. Anderson connectors provide secure, high-current connections. Our EV and new energy capabilities support complete renewable energy systems.
Pre-terminated string cables reduce installation time with factory-quality connections. Custom lengths match specific array configurations. Rapid shutdown wiring meets NEC 2017/2020 code requirements for rooftop safety. Power harnesses handle DC and AC distribution.
PV wire, USE-2, and XLPE insulated cables withstand decades of UV exposure and temperature cycling. Our testing capabilities verify electrical performance. Contact us for solar wire harness quotes for residential, commercial, or utility-scale installations.
Solar FAQ
We manufacture PV wire, USE-2, and XLPE insulated solar cables in various gauges. Our cables are rated for outdoor use with UV-resistant jacketing and meet UL 4703 and TUV standards for photovoltaic applications.
Yes, we assemble cables with MC4 and MC4-compatible connectors. We also work with other solar connector types from Amphenol, TE, and other manufacturers. All connections are properly crimped and tested.
We manufacture pre-terminated string cables cut to specific lengths with connectors installed. This reduces installation time and ensures consistent, factory-quality connections. Custom configurations are available.
We can integrate rapid shutdown components and wiring into our harness assemblies to meet NEC 2017/2020 requirements. We work with your system design to provide compliant solutions.
Need Solar Wire Harness Solutions?
UV-resistant, outdoor-rated cables for residential, commercial, and utility-scale solar installations.
